160W, 70/100V, 4Ω professional mixer amplifier complete with multimedia module with Tuner FM, MP3 player on SD MCC/USB
support and Bluetooth connection.
This new series of audio power amplifiers was designed to fulfil an evolving market in the most flexible and professional manner.
The new range responds to precise operating criteria, and was designed and tested to guarantee total reliability of use, also with
continuous operation.
Thanks to the use of power supply switching with SMPS (switch mode power supply) technology and to the constant voltage output
70/100V obtained electronically without transformers, it was possible to design the amplifier in only two rack units, succeeding in
containing the weight and size.

Model: AUP160D

Output: power RMS 160W

Inputs: 1 x balanced line Input

Sensitivity: Line: 1V/47kΩ - variable gain 600Ω

Controls: Master volume control - Treble tone control - Bass tone control

Loudspeakers outputs: 100/70V/4Ω

Frequency response: 80Hz -16KHz (-3dB)

Distortion (THD): < 0.5% (@ Pnom 1KHz)

S/N Ratio: ≥80dB Power Supply: autoswitch 100-240V~ 50/60Hz

Operating temperature: 0 -40°C

Input/Output Connectors: terminal block

Power Consumption: 160VA

Dimensions (LxHxP): 439 x 44 x 300 mm - 483 x 44 x 300 mm - 1U rack19''

Weight: 4.5Kg
